Featured Product
H-Amp-XXXV dual channel
High Power Amplifier

On Sale in webshop

H-Amp-XXXV-dual

Dual Channel High Power Amplifier

We are proud to present this "monster" of a power amplifier with more than 2000 Watts peak power in each channel @ 2 ohms

This Stereo Power Amplifier is equipped with two HPA2K power amplifier modules. The HPA2K is very detailed, very current willing yet with neutral tonal balance. The 1200VA toroidal transformer and the massive capacitor bank PSU16H is placed on an internal 15mm aluminium plate separating the power supply from the power amplifier modules. The chassis sides are precision machined, very smooth and very cool looking giving a distinct impression. The front has a near full width display indicating channel power "good" and channel clip.

The ideal Power Amplifier for "power hungry" passive divided loudspeakers like B&W 800D, B&W 801D, Wilson Audio Alexandria, Dynaudio Consequence, Vienna Acoustics Mahler or similar... This amp will be in control











Specifications:
  • Class H Power Amplifier
  • 2 x 650W @ 8 Ω
  • 2 x 1200W @ 4 Ω
  • 2 x +2kW @ 2 Ω (peak)
  • 120dB S/N
  • 10Hz-50kHz
  • 2 x 3-pol Neutrik XLR input
  • 2 x 4-pol Neutrik NLT SpeakOn output
  • Front mounted Power Switch
  • 12Vdc Remote ON/OFF
  • Mains IEC 230Vac / 50Hz
  • Dimensions: 270 x 350 x 450mm
  • Weight 45kg
